IMO 11 Pin Round DIN Rail Mount Plug In Relay Base
Part Number: BA02C
Sign in to see price & stockDelivery
We provide free delivery within a 100km radius of your local branch as part of our standard service. This applies to in-stock items and orders placed directly with your local branch.
Delivery is managed at the branch level, and restrictions may apply depending on order size, location, or access. Your branch will contact you to confirm any exceptions or additional details.
Collection
Collection orders will be ready to collect 2 hours after placing your order. This service applies to orders placed directly with your branch and is subject to stock availability.
Your branch will confirm collection details and advise of any exceptions where required.
- 10A 400V AC to suit RS3 11 pin relay
- Flame retardant material construction
- Easy DIN rail mounting
- Secure grip for anti-vibration
- IMO model number SRRE11
- For use with RL02C RL07C and RL08C
- Colour
- Black
- Current Rating
- 10A
- Depth
- 26mm
- Dimensions
- (H)61.8 mm x (W)38.1 mm x (D)26 mm
- Guarantee
- 1 Year
- Height
- 61.8mm
- Material
- Plastic
- Maximum Operating Temperature
- 70°C
- Minimum Operating Temperature
- -40°C
- Mounting
- DIN Rail
- Number Of Pins
- 11
- Packaging Types
- Each
- Product Range
- Plug-In Relays
- Standards
- EN 60947-5-1 IEC 60947-1 EN 55014-1 EN 55014 -2 EN 61000-3-2 EN 61000-3-3
- Suitable For
- RS3 Relay
- Terminal Type
- Screw
- Type
- Relay Base
- Unspsc V18
- 39122335
- Unspsc V24
- 39122335
- Voltage Rating
- 400V AC
- Weight
- 0.06kg
- Width
- 38.1mm
